GSF Staged Fuel Round Flame Burner

GSF Staged Fuel Round Flame Burner

Burner Description:

The Zeeco GSF Staged Fuel Emissions round flame gas only burner.

Burner Design Features:

  • Stable flame over a wide range of conditions
  • Turndown of 3:1 or greater for most cases
  • Low maintenance cost since tip mass is small and exposed into firebox less than 1" (25 mm)
  • Compact flame shape
  • Reasonable cost and great value
  • Combustion air is controlled by gears for precise control
  • Bearings are used for the combustion air dampers for smooth, precise operation
  • Configurations available: plenum mounted or individual wind-box
  • One (1) primary gas tip
  • Four (4) staged fuel gas tips
  • 310 Stainless Steel (Type HK) gas tips

Burner Design Information

Burner Model: GSF Staged Fuel Low Emissions Burner
Fuels: Gas Only
Description: Round Flame, Staged Fuel, Low Emissions
NOx Reduction Method: Staged Fuel
Predicted NOx Emissions Range (Natural Draft): 45 ppmv to 80 ppmv
Predicted NOx Emissions Range (600°F/316°C Air Preheat): 70 ppmv to 120 ppmv
Combustion Air Induction: Natural, Forced, Induced & Balanced Draft
Mounting Options: Up-fired and Side-fired
Natural Draft Heat Release Range: 1 MM to 20 MM Btu/hr [0.293 to 5.860 MW]
Forced Draft Heat Release Range: 1 MM to 50 MM Btu/hr [0.293 to 14.650 MW]
Turndown: 3:1
Typical Excess Air Range: 10% to 25%
Burner Data Sheet
Microsoft Excel (.xls) Format | 180 KB
