AR/GS-1 HEI High Energy Ignition Pilot Assembly

Pilot Description

The Zeeco AR/GS-1 HEI High Energy Ignition Pilot Assembly is a forced draft design.

AR/GS-1 HEI High Energy Ignition Pilot Assembly

Pilot Design Information

Pilot Model: AR/GS-1 HEI
Pilot Ignition Method: High Energy Electric Ignition
Maximum Pilot Heat Release: Up to 2 MMBtu/hr
Pilot Operating Pressure Range: 5 psig to 15 psig
Pilot Fuel Range with single tip: 100% propane to 90% hydrogen
Pilot Tip Material: HK or 310 SS
Pilot Flame Shield: HK or 310 SS
Pilot Mixer Material: Carbon Steel (Optional 304SS or 316L SS)
Pilot Riser Material: Carbon Steel (Optional 304SS or 316L SS)
Ignition Rod Material: 310 SS
Operating Range: Atmospheric to 90 psig internal pressure
