Zeeco GSI Conventional Emissions Process Burner

GSI Conventional Emissions Process Burner

Burner Description:

The Zeeco GSI Conventional Emissions Spin Mix burner is used for process Applications.

Burner Design Features:

  • Stable flame over a wide range of conditions
  • High turndown of 5:1 or greater for most cases
  • Compact Design makes this burner a great choice for retrofit applications
  • Reasonable cost and great value
  • Configurations available: plenum mounted or individual wind-box

Burner Design Information

Burner Model: GSI Conventional Emissions Burner
Fuels: Gas Only
Description: Round Flame
NOx Reduction Method: None
Predicted NOx Emissions Range: 70 to 150 ppmv wth 0% EFGR
Combustion Air Induction: Forced Draft
Mounting Options: Side-fired
Forced Draft Heat Release Range: to 65 MM Btu/hr [to 19.045 MW]
Turndown: 5:1
Typical Excess Air Range: 10%
