PSR Premixed Spider Flame Burner

PSR Premixed Spider Flame Burner

Burner Description:

The Zeeco PSR burner is a premixed burner designed to provide a spider type flame.

Burner Design Features:

  • Stable flame over a wide range of conditions
  • Turndown of 3:1 or greater for most cases
  • Reduced flashback
  • Long service life
  • Operations with a wide range of fuels
  • Cast venturi / mixer
  • 304 Stainless Steel (Type HK) gas tip

Burner Design Information

Burner Model: PSR Premixed Burner
Fuels: Gas Only
Description: Premixed spider flame burner
NOx Reduction Method: None
Predicted NOx Emissions Range (Natural Draft): 35 ppmv to 80 ppmv
Combustion Air Induction: Natural
Mounting Options: Side-fired, up-fired, & down-fired
Natural Draft Heat Release Range: 1 MM to 16 MM Btu/hr [0.293 to 4.688 MW]
Turndown: 3:1
Typical Excess Air Range: 10% to 15%
Burner Data Sheet
Microsoft Excel (.xls) Format | 180 KB
